039 - Rear Suspension - Shock Absorber And Brake Disc

001 - Crankcase

002 - Driving Shaft - Connecting Rods And Pistons

003 - R.H. Cylinder Head

004 - L.H. Cylinder Head

005 - Timing - Tappets

006 - Timing - Controls

007 - Injection Device - Ignition

008 - Pneumatics Actuator System

009 - Fuel Pumps And Pipes

010 - Fuel Tanks

011 - Air Intake Manifold

012 - Air Intake

013 - Air Intake Manifold Cover

014 - Electronic Accelerator Pedal

015 - Racing Exhaust System

016 - Lubrication System - Tank - Heater Exchange

017 - Water/Oil Pump

018 - Nourice

019 - Cooling System

020 - Cooling System Radiators

021 - Clutch And Controls

022 - Pedals

023 - Clutch And Gearbox Hydraulic Control

024 - Power Unit And Tank

025 - Gearbox - Covers

026 - Main Shaft Gears

027 - Lay Shaft Gears

028 - Inside Gearbox Controls

029 - Differential And Axle Shaft

030 - Brakes And Clutch Hydraulic Controls

031 - Brake Booster System

032 - Brake System

033 - Calipers For Front And Rear Brakes

034 - Hydraulic Steering Box And Serpentine

035 - Steering Column

036 - Hydraulic Steering Pump And Tank

037 - Front Suspension - Shock Absorber And Brake Disc

038 - Front Suspension - Wishbones

039 - Rear Suspension - Shock Absorber And Brake Disc

040 - Rear Suspension - Wishbones

041 - Wheels

042 - Battery

043 - Battery Cut-Out

044 - Current Generator - Starting Motor

045 - Current Generator - Starting Motor

100 - Body - Outer Trims

101 - Frame - Complete Front Part Structures And Plates

102 - Frame - Front Elements Structures And Plates

103 - Frame - Central Elements And Plates

104 - Frame - Rear Elements And Plates

105 - Frame - Rear Elements Sub-Groups

106 - Roof - Structure

107 - Roll-Bar

108 - Flat Floor Pan And Wheelhouse

109 - Passengers Compartment Foot-Board

110 - Front Hood And Opening Device

111 - Engine Bonnet

112 - Doors - Frameworks And Coverings

113 - Doors - Window And Rearview Mirror

114 - Front Bumper

115 - Rear Bumper

116 - Glasses And Gaskets

117 - Racing Seat

118 - Tunnel - Framework And Accessories

119 - Dashboard

120 - Instruments

121 - Front And Rear Lights

122 - Shields - Finishing

123 - Windshield And Glass Washer

124 - Electrical System

125 - Front Passengers Compartment Control Stations

126 - Front Compartment Control Stations

127 - Rear Passengers Compartment Control Stations

128 - Ventilation System

129 - Lifting System

130 - Fire-Proof System

131 - Data Acquirement

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	224339	Rear Shock Absorber Standard	- £££	2	POA (Exc VAT)	?	0
1	181402	Rear Shock Absorber Optional	-	2	POA (Exc VAT)	?	0
2	181421	Rear Spring 16Mm Wires 0.0424 mm/kg Standard- -0,0424 mm/kg	-	2	£94.99 (Exc VAT)	?	0
2	181422	Rear Spring 17Mm Wires 0.0344 mm/kg Optional- -0,0344 mm/kg	-	2	£89.99 (Exc VAT)		0
3	181409	Upper Spacer	-	2	£32.99 (Exc VAT)		0
4	181408	Lower Spacer	-	2	£30.99 (Exc VAT)		0
5	157630	Shock Absorber Bush	-	2	£69.99 (Exc VAT)		0
6	174727	Top Mount Shock Absorber	-	2	POA (Exc VAT)	?	0
7	181404	Shock Absorber Pad	-	2	POA (Exc VAT)	?	0
8	181410	Ring Nut Shock Absorber	-	2	£43.99 (Exc VAT)	?	0
9	181412	Ring Nut Shock Absorber	-	2	£21.99 (Exc VAT)	?	0
10	69424200	LH Rear Brake Duct	-	1	£199.99 (Exc VAT)	?	0
10	69424100	RH Rear Brake Duct	-	1	£189.99 (Exc VAT)	?	0
11	182533	Air Duct Tube	-	2	POA (Exc VAT)	?	0
12	181479	LH Rear Brake Duct	-	1	£309.99 (Exc VAT)	?	0
12	181478	RH Rear Brake Duct	-	1	POA (Exc VAT)	?	0
13	163323	Fixing Clip	-	4	£0.43 (Exc VAT)		0
14	10460287	Cut Insulating Ring	-	2	£1.19 (Exc VAT)		0
15	220676	Rear Ccm Brake Disc 430 Chall	-	2	£2,667.99 (Exc VAT)	?	0
16	181346	Silentbloc Bush	-	2	POA (Exc VAT)	?	0
	Superseded by 329184	Flambloc D.34	N	2	£99.99 (Exc VAT)		0
17	11306934	Screw M10 x 1.25 x 30	-	4	£0.46 (Exc VAT)		0
18	160092	Washer	-	4	£0.21 (Exc VAT)		0
19	204974	Screw	-	2	£249.99 (Exc VAT)	?	0
20	129225	Spacer	-	4	£1.39 (Exc VAT)	?	0
21	102825	Nyloc Nut 12x1.25x12	-	2	£0.76 (Exc VAT)		0
22	182508	Roll Bar Pin	-	2	£6.69 (Exc VAT)		0
23	160092	Washer	-	4	£0.21 (Exc VAT)		0
24	179778	Rear Anti Roll Bar Standard- -D. 22	-	1	£959.99 (Exc VAT)	?	0
24	210234	Rear Anti Roll Bar Optional- -D. 20	-	1	POA (Exc VAT)	?	0
25	133216	Nut M10	-	6	£7.89 (Exc VAT)	?	0
26	181465	Roll Bar Bush Outside diameter 50 mm -0,1 -0,2- -Red paint	-	2	£6.19 (Exc VAT)	?	0
26	182510	Roll Bar Bush Outside diameter 50 mm -0,35 -0,45- -Neutral paint	-	2	£35.99 (Exc VAT)		0
26	184354	Roll Bar Bush Outside diameter 50,2 mm -0 -0,1- -Green paint	-	2	£9.99 (Exc VAT)	?	0
27	182511	Roll Bar Bush	-	1	£6.89 (Exc VAT)	?	0
28	182512	Roll Bar Bush	-	1	£11.99 (Exc VAT)	?	0
29	175861	LH Roll Bar Link	-	1	£169.99 (Exc VAT)	?	0
30	170950	Allen Screw M10 x 1.25 x	-	1	£2.59 (Exc VAT)		0
31	12601474	Wavy Washer 10mm	-	1	£0.03 (Exc VAT)		0
32	220558	RH Wheel Bearing Assy	-	1	£1,763.99 (Exc VAT)	?	0
32	220562	LH Wheel Bearing Assy	-	2	£1,763.99 (Exc VAT)	?	0
33	180591	Bolt For Wheel Hubs	MP -	8	POA (Exc VAT)	?	0
34	160092	Washer	-	8	£0.21 (Exc VAT)		0
35	10732414	Washer	-	8	£6.49 (Exc VAT)	?	0
36	223160	Hub Nut M24 X 1.5	-	2	£17.99 (Exc VAT)	?	0
37	220588	Brake Disc Shroud	-	2	£159.99 (Exc VAT)	?	0
38	169088	Conn Rod Without Attachment	-	2	POA (Exc VAT)	?	0
39	223161	Washer D.43-25 X 2	-	2	£19.99 (Exc VAT)	?	0
40	220692	Stud	-	10	POA (Exc VAT)	?	0
41	224491	Spring Lever	-	2	£11.99 (Exc VAT)	?	0
