045 - Current Generator - Starting Motor

001 - Crankcase

002 - Driving Shaft - Connecting Rods And Pistons

003 - R.H. Cylinder Head

004 - L.H. Cylinder Head

005 - Timing - Tappets

006 - Timing - Controls

007 - Injection Device - Ignition

008 - Pneumatics Actuator System

009 - Fuel Pumps And Pipes

010 - Fuel Tanks

011 - Air Intake Manifold

012 - Air Intake

013 - Air Intake Manifold Cover

014 - Electronic Accelerator Pedal

015 - Racing Exhaust System

016 - Lubrication System - Tank - Heater Exchange

017 - Water/Oil Pump

018 - Nourice

019 - Cooling System

020 - Cooling System Radiators

021 - Clutch And Controls

022 - Pedals

023 - Clutch And Gearbox Hydraulic Control

024 - Power Unit And Tank

025 - Gearbox - Covers

026 - Main Shaft Gears

027 - Lay Shaft Gears

028 - Inside Gearbox Controls

029 - Differential And Axle Shaft

030 - Brakes And Clutch Hydraulic Controls

031 - Brake Booster System

032 - Brake System

033 - Calipers For Front And Rear Brakes

034 - Hydraulic Steering Box And Serpentine

035 - Steering Column

036 - Hydraulic Steering Pump And Tank

037 - Front Suspension - Shock Absorber And Brake Disc

038 - Front Suspension - Wishbones

039 - Rear Suspension - Shock Absorber And Brake Disc

040 - Rear Suspension - Wishbones

041 - Wheels

042 - Battery

043 - Battery Cut-Out

044 - Current Generator - Starting Motor

045 - Current Generator - Starting Motor

100 - Body - Outer Trims

101 - Frame - Complete Front Part Structures And Plates

102 - Frame - Front Elements Structures And Plates

103 - Frame - Central Elements And Plates

104 - Frame - Rear Elements And Plates

105 - Frame - Rear Elements Sub-Groups

106 - Roof - Structure

107 - Roll-Bar

108 - Flat Floor Pan And Wheelhouse

109 - Passengers Compartment Foot-Board

110 - Front Hood And Opening Device

111 - Engine Bonnet

112 - Doors - Frameworks And Coverings

113 - Doors - Window And Rearview Mirror

114 - Front Bumper

115 - Rear Bumper

116 - Glasses And Gaskets

117 - Racing Seat

118 - Tunnel - Framework And Accessories

119 - Dashboard

120 - Instruments

121 - Front And Rear Lights

122 - Shields - Finishing

123 - Windshield And Glass Washer

124 - Electrical System

125 - Front Passengers Compartment Control Stations

126 - Front Compartment Control Stations

127 - Rear Passengers Compartment Control Stations

128 - Ventilation System

129 - Lifting System

130 - Fire-Proof System

131 - Data Acquirement

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	205403	Alternator 150A	-	1	POA (Exc VAT)	?	0
	Superseded by 250367	Alternator 150A	N £££	1	£507.33 (Exc VAT)		0
2	14308724	Allen Screw 10x100	-	1	£2.93 (Exc VAT)		0
3	10569474	Washer	-	1	£0.05 (Exc VAT)		0
4	209278	Bush	-	1	£9.86 (Exc VAT)	?	0
5	14308224	Screw	-	1	£0.90 (Exc VAT)	?	0
6	10569474	Washer	-	1	£0.05 (Exc VAT)		0
7	164467	Bushing	-	1	£17.19 (Exc VAT)	?	0
8	207423	Spacer	-	1	£4.14 (Exc VAT)	?	0
9	187143	Threaded Bush	-	1	£5.84 (Exc VAT)	?	0
10	16102314	Nut M8 x 5	-	1	£0.06 (Exc VAT)		0
11	12601374	Wavy Washer 8mm	-	1	£0.02 (Exc VAT)		0
12	154803	Rubber Boot	-	1	£3.95 (Exc VAT)	?	0
13	192534	Cables	-	1	£170.72 (Exc VAT)	?	0
14	178356	Bracket	-	1	POA (Exc VAT)	?	0
15	10902324	Screw M6 x 18	-	2	£0.12 (Exc VAT)		0
16	127494	Wavy Washer 6mm Zinc Coated	-	2	£0.07 (Exc VAT)		0
17	12644424	Washer 6.15-15 x 1	-	2	£0.05 (Exc VAT)		0
18	180169	Starter Motor	- £££	1	£353.92 (Exc VAT)	?	0
19	222003	Engine Support	-	1	£32.53 (Exc VAT)	?	0
20	160472	Nut	-	2	£1.88 (Exc VAT)	?	0
21	61148700	Washer	-	2	£0.14 (Exc VAT)	?	0
	Superseded by 12643724	Washer 6.15-18x1.5	N	2	£0.05 (Exc VAT)		0
22	14302824	Allen Screw 8x18	-	3	£0.19 (Exc VAT)		0
23	11193874	Washer D.8.4-16x1.4	-	3	£0.05 (Exc VAT)		0
24	124683	Connector Rubber Boot	-	1	POA (Exc VAT)	?	0
25	172537	Belt Pulley	-	1	£71.94 (Exc VAT)		0
26	11234721	Bolt	-	1	£0.34 (Exc VAT)		0
27	11190574	Washer	-	1	£0.06 (Exc VAT)		0
28	225785	Tensioner	-	1	POA (Exc VAT)	?	0
29	16044431	Bolt M8 x 60	-	1	£0.32 (Exc VAT)		0
30	11193874	Washer D.8.4-16x1.4	-	1	£0.05 (Exc VAT)		0
31	219847	Belt	-	1	£76.25 (Exc VAT)	?	0
