Ferrari / 308 GT4 Dino 1979 / 039 - Electric Generating System

Reset

< Prev Next >

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Fuel System

010 - Carburetors And Air Cleaner

011 - Throttle Control

012 - Exhaust System

013 - Blow - By System

014 - Lubrication System

015 - Cooling System

016 - Water Pump And Piping

017 - Clutch Operating Control

018 - Clutch Unit And Cover

019 - Gearbox Transmission

020 - Gear - Differential Housing And Oil Sump

021 - Main Shaft Gears

022 - Lay Shaft Gears

023 - Inside Gearbox Controls

024 - Outside Gearbox Controls

025 - Differential And Axle Shaft

026 - Pedal Board - Brake And Clutch Controls

027 - Brake System

028 - Caliper For Front And Rear Brakes

029 - Hand - Brake Control

030 - Steering Box And Linkage

031 - Steering Column

032 - Front Suspension - Shock Absorber And Brake Disc

033 - Front Suspension - Wishbones

034 - Rear Suspension - Shock Absorber & Brake Disc

035 - Rear Suspension - Wishbones

036 - Wheels

037 - Engine Ignition

038 - Engine Ignition (From N. 14070 Lhd - 14020 RHD)

039 - Electric Generating System

040 - Air Conditioning System

041 - Air Conditioning Compressor And Controls

042 - Tool Kit

043 - Throttle Control (Variants For RHD Version)

044 - Pedal Board - Clutch Controls (Variants For RHD Version)

045 - Brake Hydraulic System (Variants For RHD Version)

046 - Air Pump And Piping (Variants For Usa - Aus And J Version)

047 - Guards (Variants For Usa - Aus And J Version)

048 - Antievaporative Emission Control System (Variants For Usa - Aus And J Version)

049 - Antievaporative Emission Control System (Variants For Usa - Aus And J Version)

050 - Intake Air Cleaner Valve And Lines (Variants For Usa - Aus And J Version)

051 - Intake Air Cleaner Valve And Lines (Variants For Usa - Aus And J Version)

052 - Fuel System - Carburetors And Controls (Variants For Usa - Aus And J Version)

053 - Exhaust System (Variants For Usa - Aus And J Version)

054 - Exhaust System (Variants For Usa - Aus And J Version)

055 - Engine Ignition (Variants For Usa - Aus And J Version)

101 - Body Shell - Outer Elements

102 - Body Shell - Inner Elements

103 - Body Shell - Inner Elements (Usa 78 - Aus)

104 - Body Shell - Inner Elements (Usa 77 - Aus)

105 - Body Shell - Inner Elements

106 - Front Compartment Lid

107 - Engine Compartment Lid And Carpeting

108 - Luggage Compartment Lid

109 - Doors

110 - Doors

111 - Bumpers And Moldings

112 - Bumpers (U.S. And Japanese Version)

113 - Glasses

114 - Interior Trim, Accessories And Sliding Roof

115 - Interior Trim And Accessories

116 - Seats

117 - Carpeting

118 - Instruments And Accessories

119 - Fuses And Relays

120 - Headlights Lifting Device

121 - Lights

122 - Windshield Wiper, Washer And Horn

123 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	103959	Starter Motor FIAT	- £££	1	POA (Exc VAT)	?	0
1	106966	Starter Motor BOSCH	MP - £££	1	POA (Exc VAT)	?	0
	Alternative 95130022	Pinion Bosch Starter Mtr	N	1	£197.58 (Exc VAT)		0
2	16045031	Bolt	-	3	POA (Exc VAT)	?	0
3	11198071	Washer Beville 8mm	-	3	POA (Exc VAT)	?	0
	Superseded by 11198074	Washer 8mm	N	3	£0.06 (Exc VAT)		0
4	10519621	Washer	-	3	POA (Exc VAT)	?	0
	Superseded by 10519624	Washer 8.15-17x2	N	3	£0.12 (Exc VAT)		0
5	16100811	Nut 8x6.5mm	-	1	POA (Exc VAT)	?	0
	Superseded by 16100824	Nut M8 x 6.5	N	1	£0.13 (Exc VAT)		0
5	10516670	Spring Washer 8mm	-	1	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	1	£0.05 (Exc VAT)		0
6	107038	Shield Not For USA, AUS & JAP	-	1	POA (Exc VAT)	?	0
7	107039	Bracket Not For USA, AUS & JAP	-	1	POA (Exc VAT)	?	0
8	15896211	Nut M6 x 5 Not For USA, AUS & JAP	-	1	£0.06 (Exc VAT)		0
9	12643701	Flat Washer Not For USA, AUS & JAP	-	1	£0.05 (Exc VAT)		0
10	107129	Starter Motor Rear Bracket	-	1	£47.08 (Exc VAT)		0
11	15970721	Bolt M10 x 1.25 x 25 UNI 5740	-	1	£0.30 (Exc VAT)		0
12	105391	Washer	-	1	£2.33 (Exc VAT)		0
13	106853	Spring Washer 10mm	-	1	POA (Exc VAT)	?	0
	Superseded by 12601474	Wavy Washer 10mm	N	1	£0.03 (Exc VAT)		0
14	106850	Spring Washer 6mm	-	2	POA (Exc VAT)	?	0
	Superseded by 127494	Wavy Washer 6mm Zinc Coated	N	2	£0.07 (Exc VAT)		0
15	15896211	Nut M6 x 5	-	2	£0.06 (Exc VAT)		0
16	111680	Alternator Use on Exhaustion of 106541	MP - £££	1	POA (Exc VAT)	?	0
17	107003	Connector Rubber Boot	-	1	POA (Exc VAT)	?	0
	Alternative 107003/A	Connector Rubber Boot	MP N	1	£22.69 (Exc VAT)		0
18	106989	Alternator Wiring Loom	-	1	£65.07 (Exc VAT)		0
19	106543	Washer	-	1	POA (Exc VAT)	?	0
20	106544	Fan For Alternator N106541	-	1	POA (Exc VAT)	?	0
20	110111	Fan For Alternator N111680	-	1	£26.22 (Exc VAT)	?	0
21	107221	Shield	-	1	POA (Exc VAT)	?	0
22	106849	Spring Washer	-	4	POA (Exc VAT)	?	0
	Superseded by 127493	Spring Washer 5mm	N	4	£0.07 (Exc VAT)		0
23	15896411	RH Thread Nut	-	4	POA (Exc VAT)	?	0
	Superseded by 15896414	Nut	N	4	£0.06 (Exc VAT)		0
24	107396	Regulator Std 13.8V	-	1	POA (Exc VAT)	?	0
25	105940	Alternator Bracket	MP -	1	£53.63 (Exc VAT)		0
26	105158	Support	-	1	POA (Exc VAT)	?	0
27	105392	Bush For Alternator N106541	-	1	£16.53 (Exc VAT)		0
28	105393	Washer For Alternator N106541	-	1	POA (Exc VAT)	?	0
28	106426	Washer For Alternator N111680	-	1	£1.15 (Exc VAT)		0
29	105390	Bolt	-	1	POA (Exc VAT)	?	0
	Superseded by 15541821	Bolt	N	1	£14.26 (Exc VAT)		0
30	11198671	Washer	-	1	POA (Exc VAT)	?	0
	Superseded by 11198673	Washer	N	1	£0.96 (Exc VAT)		0
31	16109221	Self Locking Nut M12 x 1.25	-	1	£3.59 (Exc VAT)	?	0
32	106228	Screw For Alternator N106541	-	1	POA (Exc VAT)	?	0
	Superseded by 15970931	Bolt	N	1	£5.83 (Exc VAT)		0
32	15970931	Bolt For Alternator N111680	-	1	£5.83 (Exc VAT)		0
33	13598021	Self Locking Nut	-	1	POA (Exc VAT)	?	0
	Alternative 102742	Nyloc Nut M10x1.25x10	N	1	£0.34 (Exc VAT)		0
34	106229	Washer For Alternator N106541	-	1	POA (Exc VAT)	?	0
34	105931	Spacer 0.7mm For Alternator N111680	-	1	£0.64 (Exc VAT)		0
35	106542	Alternator Pulley	MP -	1	£251.30 (Exc VAT)		0
36	104336	Alternator Belt 975mm	MP -	1	£57.55 (Exc VAT)		0
37	16100811	Nut 8x6.5mm	-	1	POA (Exc VAT)	?	0
38	106852	Spring Washer 8mm	-	1	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	1	£0.05 (Exc VAT)		0
39	16100811	Nut 8x6.5mm	-	1	POA (Exc VAT)	?	0
40	10516670	Spring Washer 8mm	-	1	POA (Exc VAT)	?	0
41	107079	Cable	-	1	£102.39 (Exc VAT)	?	0
42	107547	Battery Earth Cable	-	1	POA (Exc VAT)	?	0
43	107630	Battery 12V - 60AH Dry Not For USA & JAP	-	1	POA (Exc VAT)	?	0
43	104163	Battery 12V 66AH 300A MARELLI Alternatively Use 107630	-	1	POA (Exc VAT)	?	0
44	106525	Battery Bracket	MP -	1	£64.26 (Exc VAT)		0
45	100901	Earth Cable	-	1	POA (Exc VAT)	?	0
46	105694	Battery Strap	-	2	POA (Exc VAT)	?	0
47	16100821	Plain Nut 8mm x 6.25mm Pitch 1.25	-	1	POA (Exc VAT)	?	0
	Superseded by 16102314	Nut M8 x 5	N	1	£0.06 (Exc VAT)		0
48	12603171	Washer	-	1	POA (Exc VAT)	?	0
