Ferrari / 275 GTS / 018 - Transmission Shaft

Reset

< Prev Next >

001 - Crankcase

002 - Oil Sump

003 - Crankshaft, Con Rods & Pistons

004 - Cylinder Head

004A - Cylinder Heads - LHD Upto 31-12-1965

004B - Cylinder Heads - RHD Variants

005 - Carburettors Weber 40 Dcz/6

006 - Inlet Manifolds

007 - Fuel System

007A - Fuel System - RHD Variants

008 - Exhaust & Manifolds

009 - Timing Control

009A - Timing Comtrol - RHD Variants

010 - Oil Pump & Filters

011 - Engine Ignition

011A - Engine Ignition - LHD Upto 31-12-1965

012 - Generator - Battery & Coils

012A - Generator - Battery & Coils - LHD Upto 31-12-1965

012B - Generator - Battery & Coils - RHD Variants

013 - Clutch

013A - Clutch - LHD Upto 31-12-1965

014 - Gearbox Casing - Differential

015 - Primary Shaft

016 - Secondary Shaft

017 - Oil Pump & Linkage

018 - Transmission Shaft

018A - Transmission Shaft - LHD Upto 31-12-1965

019 - Differential & Driveshaft

019A - Differential & Driveshaft - LHD Upto 31-12-1965

020 - Rear Suspension

020A - Rear Suspension - LHD Upto 31-12-1965

021 - Front Suspension

021A - Front Suspension - LHD Upto 31-12-1965

022 - Pedal Box

022A - Pedal Box - LHD Upto 31-12-1965

022B - Pedal Box - RHD Variants

023 - Brake System

023A - Brake System - RHD Variants

023B - Brake System - RHD Variants

023C - Brake System - RHD Variants

024 - Brake Discs & Master Cylinder

024A - Brake Discs & Master Cylinder - LHD Upto 31-12-1965

025 - Front Rear & Hand Brake Caliper

025A - Front Rear & Hand Brake Caliper - RHD Variants

026 - Tyres Wheels & Shaft

026A - Tyres Wheels & Shaft - LHD Upto 31-12-1965

027 - Steering Box

028 - Steering Column

029 - Steering Linkage

029A - Steering Linkage - LHD Upto 31-12-1965

029B - Steering Linkage - RHD Variants

030 - Radiator & Water Pump

030A - Radiator & Water Pump - LHD Upto 31-12-1965

031 - Fuel Tank

031A - Fuel Tank - LHD Upto 31-12-1965

203A - Front Body Panels

203B - Front Body Panels

203C - Front Body Panels 365GTS

204 - Rear Body Panels

205A - Bonnet Components

205B - Bonnet Components

205C - Bonnet Components

207A - Door Components

207B - Door Components

207C - Door Components 365GTS

208 - Boot Components

212 - Radiator Grille

213 - Windscreen Components

215 - External Side Trim

216A - Carpets

216B - Carpets

216C - Carpets

217A - Bituminous Insulation

217B - Bituminous Insulation

218A - Interior Cabinet Accessories

218B - Interior Cabinet Accessories

218C - Interior Cabinet Accessories 365GTS

219A - Seats

219B - Seats

220 - Number Plate Frames

221A - Dashboard Components

221B - Dashboard Components

221C - Dashboard Components

222A - Console Variations 330GTS

222B - Console Variations 365GTS

223A - System Electrics

223B - System Electrics

223C - System Electrics 365GTS

224 - Front And Rear Lights

225 - Windscreen Wipers

226A - Heating And Ventilation

226B - Heating And Ventilation

226C - Heating And Ventilation 365GTS

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	560008	Drive Line Flange GTB2 Solid	-	1	POA (Exc VAT)	?	0
2	103181	Nut 8x1	MP -	1	£1.94 (Exc VAT)		0
3	10516670	Spring Washer 8mm	-	1	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	1	£0.05 (Exc VAT)		0
4	102294	Bolt	MP -	1	£2.50 (Exc VAT)		0
5	560218	275GTB2 Drive Line (1040mm)	-	1	POA (Exc VAT)	?	0
6	95850611	Compensator Ring Bush	-	1	£3.65 (Exc VAT)		0
7	560175	Drive Line Bearing/Split Bush	MP -	1	£99.81 (Exc VAT)		0
8	560176	Drive Line Support	-	1	POA (Exc VAT)	?	0
9	95891401	Double Sealed Ball Race Self Aligning	MP -	1	£63.25 (Exc VAT)		0
10	560174	Spacer	MP -	1	£0.53 (Exc VAT)	?	0
11	92266	Camshaft Sprocket Retaining Bolt	MP -	1	£23.45 (Exc VAT)		0
12	560173	Rubber Bush	MP -	1	£28.02 (Exc VAT)		0
13	560261	Spacer Shim	-	1	POA (Exc VAT)	?	0
14	95880524	Bolt	-	1	£1.46 (Exc VAT)		0
15	103181	Nut 8x1	MP -	1	£1.94 (Exc VAT)		0
