043 - Pedal Board - Clutch Control (Variants For RHD Versions)

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Fuel Pump And Pipes

010 - Fuel Injection System - Fuel Distributors, Lines

011 - Air Intake And Manifolds

012 - Throttle Housing And Linkage

013 - Exhaust System

014 - Blow - By System

015 - Lubrication System

016 - Cooling System

017 - Water Pump And Piping

018 - Clutch And Controls

019 - Gearbox Transmission

020 - Gearbox - Differential Housing And Oil Sump

021 - Main Shaft Gears

022 - Lay Shaft Gears

023 - Inside Gearbox Controls

024 - Outside Gearbox Controls

025 - Differential And Axle Shafts

026 - Pedal Board - Brake And Clutch Controls

027 - Brake System

028 - Calipers For Front And Rear Brakes

029 - Hand-Brake Control

030 - Steering Box And Linkage

031 - Steering Column

032 - Front Suspension - Shock Absorber And Brake Disc

033 - Front Suspension - Wishbones

034 - Rear Suspension - Shock Absorber And Brake Disc

035 - Rear Suspension - Wishbones

036 - Wheels

037 - Engine Ignition

038 - Electric Generating System

039 - Air Conditioning System

040 - Air Conditioning Compressor And Controls

041 - Tool-Kit

042 - Throttle Control (Variants For RHD Versions)

043 - Pedal Board - Clutch Control (Variants For RHD Versions)

044 - Brake Hydraulic System (Variants For RHD Versions)

101 - Body Shell - Outer Elements

102 - Body Shell - Inner Elements

103 - Body Shell - Inner Elements

104 - Passenger And Luggage Compartments Insulation

105 - Front Compartment Lid

106 - Rear Bonnet And Luggage Compartment Covering

107 - Doors

108 - Bumpers And Moldings

109 - Glasses

110 - Interior Trim, Accessories And Seats

111 - Tunnel And Roof Table

112 - Instrument Panel

113 - Instruments And Accessories

114 - Fuses And Relays

115 - Headlights Lifting Device

116 - Lights

117 - Windshield Wiper, Washer And Horn

118 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	116513	Clutch Pedal	-	1	£165.47 (Exc VAT)		0
2	100423	Rose Bearing	-	3	£23.06 (Exc VAT)		0
3	103163	Bush	-	2	£5.31 (Exc VAT)		0
4	106949	Pedal Rubber	MP -	1	£20.99 (Exc VAT)		0
5	117374	Spring	-	1	£9.04 (Exc VAT)		0
6	104896	Clevis Pin	-	1	£27.67 (Exc VAT)		0
7	100861	RH Thread Nut	MP -	1	£5.23 (Exc VAT)		0
8	103218	Clevis Pin	MP -	1	£18.51 (Exc VAT)		0
9	106070	Support	-	2	£75.25 (Exc VAT)		0
10	106751	Shaft	-	1	£514.30 (Exc VAT)	?	0
11	106102	Rose Bearing	MP -	2	£45.31 (Exc VAT)		0
12	108343	Adjuster Rod	-	1	£35.07 (Exc VAT)		0
13	106901	LH Clutch Fork Filetto Sx.	-	1	POA (Exc VAT)	?	0
14	106594	RH Clutch Fork Filetto Dx.	-	1	£9.55 (Exc VAT)		0
15	16102911	LH Thread Nut Filetto Sx.	-	1	POA (Exc VAT)	?	0
	Superseded by 16102914	Nut E M8 x 5 LH Thread	N	1	£4.39 (Exc VAT)		0
16	16102311	RH Thread Nut Filetto Dx.	-	1	£0.19 (Exc VAT)	?	0
	Superseded by 16102314	Nut M8 x 5	N	1	£0.06 (Exc VAT)		0
17	10004910	Clevis Pin	-	2	POA (Exc VAT)	?	0
	Alternative 103218	Clevis Pin	MP N	2	£18.51 (Exc VAT)		0
18	12639701	Washer	-	3	POA (Exc VAT)	?	0
19	10734201	Split Pin	-	3	POA (Exc VAT)	?	0
	Superseded by 10734208	Split Pin D. 2 x 12	N	3	£0.02 (Exc VAT)		0
20	106120	Rubber Boot	-	1	POA (Exc VAT)	?	0
21	16135921	Bolt	-	4	£2.49 (Exc VAT)	?	0
	Superseded by 16135924	Screw M8 x 30	N	4	£1.09 (Exc VAT)		0
22	12601371	Washer	-	4	POA (Exc VAT)	?	0
	Superseded by 12601374	Wavy Washer 8mm	N	4	£0.02 (Exc VAT)		0
23	108342	Clutch Cable RHD	MP -	1	£77.27 (Exc VAT)		0
24	16103611	Nut	-	1	£0.39 (Exc VAT)		0
25	12601571	Washer	-	1	POA (Exc VAT)	?	0
	Superseded by 12646724	Washer 8.45-20x2	N	1	£0.09 (Exc VAT)		0
26	100856	Fork	-	1	£54.20 (Exc VAT)		0
27	107878	Pedal Support Complete RHD	- £££	1	£1,480.91 (Exc VAT)		0
27	106069	Pedal Support RHD Col complessivo n. 107878	-	1	POA (Exc VAT)	?	0
	Superseded by 107878	Pedal Support Complete RHD	N £££	1	£1,480.91 (Exc VAT)		0
28	106109	Gasket	-	1	POA (Exc VAT)	?	0
29	104900	Pin	-	1	£105.63 (Exc VAT)		0
30	104901	Roll Pin	-	1	£1.76 (Exc VAT)		0
31	106110	Spacer	-	1	£21.09 (Exc VAT)		0
32	104904	Cover RHD Per vettura senza A.C	-	1	POA (Exc VAT)	?	0
32	112116	Pedal Box Cover Per vettura con A.C.	-	1	£29.50 (Exc VAT)		0
33	104905	Gasket	-	1	£8.94 (Exc VAT)		0
34	105510	Heli Coil	-	2	POA (Exc VAT)	?	0
35	16043621	Screw	-	2	POA (Exc VAT)	?	0
	Superseded by 16043624	Screw M8 x 25	N	2	£0.17 (Exc VAT)		0
36	106852	Spring Washer 8mm	-	2	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	2	£0.05 (Exc VAT)		0
37	16139021	Bolt	-	2	£2.57 (Exc VAT)		0
38	12601471	Washer	-	2	POA (Exc VAT)	?	0
	Superseded by 12601474	Wavy Washer 10mm	N	2	£0.03 (Exc VAT)		0
39	11500021	Stud	-	4	POA (Exc VAT)	?	0
40	106850	Spring Washer 6mm	-	4	POA (Exc VAT)	?	0
	Superseded by 127494	Wavy Washer 6mm Zinc Coated	N	4	£0.07 (Exc VAT)		0
41	15896211	Nut M6 x 5 .	-	4	£0.06 (Exc VAT)		0
