031 - Calipers For Front And Rear Brakes (Valid Only For Lhd Up To Chassis No. 43011)

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Fuel Pump And Pipes (Quattrovalvole)

010 - Fuel Pump And Pipes (Cabriolet)

011 - Fuel Injection System - Fuel Distributors, Line

012 - Air Intake And Manifolds

013 - Throttle Housing And Linkage

014 - Exhaust System

015 - Blow - By System

016 - Lubrication System

017 - Cooling System

018 - Water Pump And Piping

019 - Clutch And Controls

020 - Clutch Release Control

021 - Gearbox Transmission

022 - Gearbox - Differential Housing And Oil Sump

023 - Main Shaft Gears

024 - Lay Shaft Gears

025 - Inside Gearbox Controls

026 - Outside Gearbox Controls

027 - Differential And Axle Shafts

028 - Brake Hydraulic System

029 - Brake System (Valid Only For Lhd Up To Chassis No. 43011)

030 - Brake System (Valid For RHD - For Lhd From Chassis No. 43013)

031 - Calipers For Front And Rear Brakes (Valid Only For Lhd Up To Chassis No. 43011)

032 - Calipers For Front And Rear Brakes (Valid For RHD-For Lhd From Chassis No. 43013)

033 - Hand - Brake Control (Valid Only For Lhd Up To Chassis No. 43011)

034 - Hand - Brake Control (Valid For RHD - For Lhd From Chassis No. 43013)

035 - Steering Box And Linkage

036 - Steering Column

037 - Front Suspension - Shock Absorber And Brake Disc

038 - Front Suspension - Wishbones

039 - Rear Suspension - Shock Absorber And Brake Disc

040 - Rear Suspension - Wishbones

041 - Wheels

042 - Engine Ignition - (Quattrovalvole)

043 - Engine Ignition - (Cabriolet)

044 - Electric Generating System - (Engine With Single Belt)

045 - Electric Generating System - (Engine With 2 Belts)

046 - Air Conditioning Compressor And Controls

047 - Tool Kit

048 - Pedal Board - Clutch Control (Variants For RHD)

049 - Throttle Control And Brake Hydraulic System (Variants For RHD)

101 - Body Shell - Outer Elements

102 - Body Shell - Inner Elements

103 - Body Shell - Inner Elements - Quattrovalvole

104 - Body Shell - Inner Elements - Cabriolet

105 - Luggage And Passenger Compartment Insulation

106 - Quattrovalvole Luggage And Passenger Compartment

107 - Front Compartment Lid

108 - Engine Compartment Lid And Carpeting

109 - Luggage Compartment Lid

110 - Doors - Quattrovalvole

111 - Doors - Cabriolet

112 - Bumpers, Lights And Front Glasses

113 - Bumpers, Lights And Rear Glasses

114 - Seats - Quattrovalvole

115 - Seats - Cabriolet

116 - Roof, Tunnel And Safety Belts

117 - Instrument Panel

118 - Instruments

119 - Lights Lifting Device And Headlights

120 - Electrical Board

121 - Windshield Wiper - Washer And Horn

122 - Heating System

123 - Electrical System

124 - Sun Roof - Quattrovalvole

125 - Top - Cabriolet

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
-	-	FRONT BRAKE CALIPERS	-	0	POA		0
-F	115768	RH Front Caliper FERODO I/D 332	-	1	£573.62 (Exc VAT)		0
-F	115769	LH Front Caliper FERODO I/D 332	-	1	£573.62 (Exc VAT)		0
1F	117411	Front Brake Pad Set FERODO I/D 332	MP -	1	£99.82 (Exc VAT)		0
2F	112821	Caliper Bolt	MP -	4	£26.12 (Exc VAT)		0
3F	108918	Washer 0.2mm Possible fitting	-	4	POA (Exc VAT)	?	0
	Superseded by 156260	Spacer 0.2mm	N	4	£1.09 (Exc VAT)		0
3F	108919	Washer 0.3mm Possible fitting	-	4	POA (Exc VAT)	?	0
3F	108920	Washer 0.5mm Possible fitting	-	4	POA (Exc VAT)	?	0
	Superseded by 156262	Spacer 0.5mm	N	4	£1.09 (Exc VAT)		0
3F	108921	Washer 0.6mm Possible fitting	-	4	POA (Exc VAT)	?	0
	Superseded by 156263	Spacer 0.6mm	N	4	£1.09 (Exc VAT)		0
3F	108922	Washer 0.7mm Possible fitting	-	4	POA (Exc VAT)	?	0
3F	108923	Washer 0.8mm Possible fitting	-	4	POA (Exc VAT)	?	0
3F	108924	Washer 1.0mm Possible fitting	-	4	POA (Exc VAT)	?	0
	Superseded by 156266	Spacer 1.0mm	N	4	£1.09 (Exc VAT)		0
4F	116396	LH Bracket	-	2	£33.25 (Exc VAT)		0
5F	116489	Brake Hose 400mm	-	2	POA (Exc VAT)	?	0
	Alternative 116489/B	Brake Hose 400mm	N	2	£66.56 (Exc VAT)		0
6F	105856	Brake Pipe 250mm	-	2	POA (Exc VAT)	?	0
7F	106854	Spring Washer 12mm	-	4	POA (Exc VAT)	?	0
	Superseded by 127498	Spring Washer 12mm	N	4	£0.12 (Exc VAT)		0
8F	116374	Clip	-	4	£1.99 (Exc VAT)		0
9F	ATE	Pin for pads With kit no. 117411	-	2	POA		0
10F	ATE	Brake cylinder Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	4	POA		0
11F	95691535	Front Caliper Repair Kit	-	1	POA (Exc VAT)	?	0
	Alternative MC3051/2	Front Caliper Repair Kit 246/308	MP N	1	£101.43 (Exc VAT)		0
11F	ATE	Sealing ring With assembly no. 95651535	-	4	POA		0
12F	ATE	Dust protection ring With assembly no. 95651535	-	4	POA		0
13F	ATE	Stop ring Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	4	POA		0
14F	ATE	Pad pressure spring With kit no. 117411	-	2	POA		0
15F	ATE	Bolt Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	4	POA		0
16F	ATE	Nut Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	4	POA		0
17F	ATE	Cylinder body, outside Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	2	POA		0
18F	ATE	Cylinder body, inside Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	2	POA		0
19F	ATE	Upper spacer Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	2	POA		0
20F	ATE	Lower spacer Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	2	POA		0
21F	ATE	Sealing ring on spacer Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	8	POA		0
22F	ATE	Bleeder Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	2	POA		0
23F	ATE	Bleeder cap Not available as spare parts but are supplied with assembly no.s 115768 and 115769	-	2	POA		0
-	-	REAR BRAKE CALIPERS	-	0	POA		0
-R	115774	RH Rear Caliper FERODO I/D 332	-	1	POA (Exc VAT)	?	0
-R	115775	LH Rear Caliper FERODO I/D 332	- £££	1	POA (Exc VAT)	?	0
1R	117412	Rear Brake Pad Set FERODO I/D 332	-	1	£87.99 (Exc VAT)		0
2R	112821	Caliper Bolt	MP -	4	£26.12 (Exc VAT)		0
3R	108918	Washer 0.2mm Possible fitting	-	4	POA (Exc VAT)	?	0
3R	108919	Washer 0.3mm	-	4	POA (Exc VAT)	?	0
3R	108920	Washer 0.5mm	-	4	POA (Exc VAT)	?	0
3R	108921	Washer 0.6mm	-	4	POA (Exc VAT)	?	0
3R	108922	Washer 0.7mm	-	4	POA (Exc VAT)	?	0
3R	108923	Washer 0.8mm	-	4	POA (Exc VAT)	?	0
3R	108924	Washer 1.0mm	-	4	POA (Exc VAT)	?	0
4R	116394	RH Bracket	-	2	£7.23 (Exc VAT)	?	0
4R	116395	LH Bracket	-	2	£7.60 (Exc VAT)		0
5R	116373	Rubber Pipe 330mm	-	2	POA (Exc VAT)	?	0
	Superseded by 977802	Flexible Brake Hose L 330mm	N	2	£32.99 (Exc VAT)		0
6R	101401	Brake Pipe LHD	-	2	POA (Exc VAT)	?	0
7R	10517071	Washer	-	4	POA (Exc VAT)	?	0
	Alternative 127498	Spring Washer 12mm	N	4	£0.12 (Exc VAT)		0
8R	116374	Clip	-	4	£1.99 (Exc VAT)		0
9R	ATE	Stop ring Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
10R	ATE	Brake cylinder Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	4	POA		0
11R	95691536	Rear Caliper Repair Kit	MP -	1	£53.98 (Exc VAT)		0
11R	ATE	Sealing ring With assembly no. 95691536	-	4	POA		0
12R	ATE	Dust protection ring With assembly no. 95691536	-	4	POA		0
13R	ATE	Stop ring Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	4	POA		0
14R	ATE	Pad pressure spring With kit no. 117412	-	2	POA		0
15R	ATE	Bolt Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	4	POA		0
16R	ATE	Nut Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	4	POA		0
17R	ATE	Cylinder body, outside Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
18R	ATE	Cylinder body, inside Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
19R	ATE	Upper spacer Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
20R	ATE	Lower spacer Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
21R	ATE	Sealing ring on spacer Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	8	POA		0
22R	ATE	Bleeder Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
23R	ATE	Bleeder cap Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
24R	ATE	Pin for pads With kit no. 117412	-	4	POA		0
25R	ATE	Clamp for pin Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	4	POA		0
26R	ATE	Bushing Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
27R	ATE	Spring Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
28R	ATE	Washer Not available as spare parts but are supplied with assembly nos. 115774 and 115775	-	2	POA		0
