Maserati / GranSport Spyder 2006 4200 cc CAMBIOCORSA / C9.50 - 2 - C950 - 2 Dashboard Unit

Reset

< Prev Next >

M1.00 - 1 - M100 - 1 Crankcase

M1.10 - 1 - M110 - 1 Crankshaft, Connecting Rods And Pistons

M1.20 - 1 - M120 - 1 Rh Cylinder Head

M1.21 - 1 - M121 - 1 Lh Cylinder Head

M1.22 - 1 - M122 - 1 Timing - Shafts And Valves

M1.24 - 1 - M124 - 1 Timing - Controls

M1.40 - 1 - M140 - 1 Intake Manifold And Throttle Body

M1.42 - 1 - M142 - 1 Fuel Tank

M1.43 - 1 - M143 - 1 Fuel Pumps And Connection Lines

M1.44 - 1 - M144 - 1 Antievaporation System

M1.44 - 2 - M144 - 2 Antievaporation System

M1.50 - 1 - M150 - 1 Additional Air System

M1.60 - 1 - M160 - 1 Lubrication System: Circuit And Collection

M1.61 - 1 - M161 - 1 Lubrication System: Pump And Filter

M1.63 - 1 - M163 - 1 Oil Vapour Recirculation System

M1.70 - 1 - M170 - 1 Cooling: Air Radiators And Ducts

M1.71 - 1 - M171 - 1 Cooling System: Nourice And Lines

M1.71 - 2 - M171 - 2 Cooling System: Nourice And Lines

M1.80 - 1 - M180 - 1 Pre-Catalytic Converters And Catalytic Converters

M1.81 - 1 - M181 - 1 Silencers

M1.90 - 1 - M190 - 1 Injection - Ignition Device

M1.91 - 1 - M191 - 1 Alternator And Starting Motor

M2.11 - 1 - M211 - 1 Friction Discs And Housing For F1 Gearbox

M3.10 - 1 - M310 - 1 Gearbox Housings

M3.11 - 1 - M311 - 1 Main Shaft Gears

M3.12 - 1 - M312 - 1 Lay Shaft Gears

M3.13 - 1 - M313 - 1 Inner Controls

M3.21 - 1 - M321 - 1 Differential And Rear Axle Shafts

M3.22 - 1 - M322 - 1 Differential Box And Rear Underbody

M3.30 - 1 - M330 - 1 Transmission Shaft

M3.40 - 1 - M340 - 1 F1 Clutch Hydraulic Control

M3.41 - 1 - M341 - 1 Power Unit And Tank

M4.00 - 1 - M400 - 1 Brakes And Clutch Hydraulic Controls

M4.12 - 1 - M412 - 1 Braking Devices On Wheels

M4.20 - 1 - M420 - 1 Braking System

M4.20 - 2 - M420 - 2 Braking System

M4.30 - 1 - M430 - 1 Parking Brake

M5.00 - 1 - M500 - 1 Steering Column And Steering Wheel Unit

M5.10 - 1 - M510 - 1 Steering Rack And Hydraulic Steering Pump

M5.20 - 1 - M520 - 1 Complete Pedal Board Unit

M5.20 - 2 - M520 - 2 Complete Pedal Board Unit

M6.00 - 1 - M600 - 1 Wheels And Tyres

M6.10 - 1 - M610 - 1 Front Suspension

M6.11 - 1 - M611 - 1 Front Shock Absorber Devices

M6.12 - 1 - M612 - 1 Front Underchassis

M6.20 - 1 - M620 - 1 Rear Suspension

M6.21 - 1 - M621 - 1 Rear Shock Absorber Devices

M7.30 - 1 - M730 - 1 Accessories Provided

M7.30 - 2 - M730 - 2 Accessories Provided

M8.20 - 1 - M820 - 1 Battery

C7.00 - 1 - C700 - 1 Airbag System

C8.00 - 1 - C800 - 1 Windscreen Wiper, Windscreen Washer And Horns

C8.33 - 1 - C833 - 1 Light Clusters

C8.33 - 2 - C833 - 2 Light Clusters

C8.40 - 1 - C840 - 1 A/C Unit: Engine Compartment Devices

C8.41 - 1 - C841 - 1 A/C Unit: Dashboard Devices

C8.50 - 1 - C850 - 1 Passenger Compartment Devices

C8.50 - 2 - C850 - 2 Passenger Compartment Devices

C8.53 - 1 - C853 - 1 Alarm And Immobilizer System

C8.53 - 2 - C853 - 2 Alarm And Immobilizer System

C8.53 - 3 - C853 - 3 Alarm And Immobilizer System

C8.60 - 1 - C860 - 1 Main Wiring

C8.71 - 1 - C871 - 1 It System

C8.71 - 2 - C871 - 2 It System

C8.73 - 1 - C873 - 1 Engine Compartment Control Units

C8.74 - 1 - C874 - 1 Passenger Compartment Control Units

C8.74 - 2 - C874 - 2 Passenger Compartment Control Units

C8.75 - 1 - C875 - 1 Trunk Compartment Control Units

C8.75 - 2 - C875 - 2 Trunk Compartment Control Units

C9.00 - 1 - C900 - 1 Bodywork And Front Outer Trim Panels

C9.02 - 1 - C902 - 1 Bodywork And Rear Outer Trim Panels

C9.03 - 1 - C903 - 1 Front Structural Frames And Sheet Panels

C9.04 - 1 - C904 - 1 Central Structural Frames And Sheet Panels

C9.05 - 1 - C905 - 1 Rear Structural Frames And Sheet Panels

C9.10 - 1 - C910 - 1 Front Bumper

C9.11 - 1 - C911 - 1 Rear Bumper

C9.13 - 1 - C913 - 1 Wheelhouse And Lids

C9.15 - 1 - C915 - 1 Shields, Trims And Covering Panels

C9.17 - 1 - C917 - 1 Stickers And Labels

C9.20 - 1 - C920 - 1 Front Lid

C9.21 - 1 - C921 - 1 Rear Lid

C9.30 - 1 - C930 - 1 Front Doors: Trim Panels

C9.31 - 1 - C931 - 1 Front Doors: Mechanisms

C9.34 - 1 - C934 - 1 Windows And Window Strips

C9.35 - 1 - C935 - 1 Glass Lift And External Rear-View Mirrors

C9.40 - 1 - C940 - 1 Front Seats: Trim Panels

C9.41 - 1 - C941 - 1 Front Seats: Mechanics And Electronics

C9.44 - 1 - C944 - 1 Inner Trims

C9.45 - 1 - C945 - 1 Roof Panel Upholstery And Accessories

C9.50 - 1 - C950 - 1 Dashboard Unit

C9.50 - 2 - C950 - 2 Dashboard Unit

C9.51 - 1 - C951 - 1 Accessory Console And Centre Console

C9.52 - 1 - C952 - 1 Glove Compartments

C9.60 - 1 - C960 - 1 Passenger Compartment Mats

C9.61 - 1 - C961 - 1 Trunk Hood Compartment Trims

C9.80 - 1 - C980 - 1 Electrical Capote: Linings

C9.81 - 1 - C981 - 1 Electrical Capote: Covers

C9.84 - 1 - C984 - 1 Electrical Capote: Closings

C9.86 - 1 - C986 - 1 Electrical Capote: Structure

C9.88 - 1 - C988 - 1 Electrical Capote: Hydraulic System

C9.89 - 1 - C989 - 1 Electrical Capote: Electronic Control

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	98261....	DASHBOARD ASSEMBLY Leather/Texture lining- -Standard- -For order specify car number	-	1	POA		0
1	98421....	DASHBOARD ASSEMBLY Leather lining- -Standard- -For order specify car number	-	1	POA		0
1	98262....	DASHBOARD ASSEMBLY Leather/Texture lining- -Optional- -Xeno Headlight- -For order specify car number	-	1	POA		0
1	98422....	DASHBOARD ASSEMBLY Leather lining- -Optional- -Xeno Headlight- -For order specify car number	-	1	POA		0
2	9811038..	R.H. LATERAL BODY IN THEDASHBOARD Texture lining- -For order specify car number	-	1	POA		0
2	9811038..	R.H. LATERAL BODY IN THEDASHBOARD Leather lining- -For order specify car number	-	1	POA		0
3	9811037..	L.H. LATERAL BODY IN THEDASHBOARD Texture lining- -For order specify car number	-	1	POA		0
3	9811037..	L.H. LATERAL BODY IN THEDASHBOARD Leather lining- -For order specify car number	-	1	POA		0
4	382300427	Side vent fastening plate Valid till stock exhaustion	-	2	£8.00 (Exc VAT)	?	0
4	69270800	Side vent fastening plate Valid after stock exhaustion of 382300427	-	2	£8.00 (Exc VAT)	?	0
5	382310395	Crossmember	-	1	£219.00 (Exc VAT)	?	0
6	9811040..	SUBINSTRUMENT Texture lining- -For order specify car number	-	1	POA		0
6	9811040..	SUBINSTRUMENT Leather lining- -For order specify car number	-	1	POA		0
7	676986..	COMPLETE UPPER INSERT IN THE DASHBOARD For order specify car number	-	1	POA		0
8	382300805	Air Deflector Vent	-	1	£209.00 (Exc VAT)	?	0
9	382300423	Clip	-	1	£2.40 (Exc VAT)	?	0
10	13274177	Screw	-	2	£1.65 (Exc VAT)	?	0
10	13274077	Screw 5x12	-	2	£1.35 (Exc VAT)	?	0
11	12637821	Split Washer	-	2	£1.10 (Exc VAT)	?	0
12	67293500	Upper Frame	-	1	£166.00 (Exc VAT)	?	0
14	382300603	LH Auto Adhesive Sponge	-	1	£2.45 (Exc VAT)	?	0
14	382300602	RH Auto Adhesive Sponge	-	1	£2.45 (Exc VAT)	?	0
15	382300800	Centre Air Vent	-	2	£65.40 (Exc VAT)	?	0
16	382300803	Air Diffuser Fixing Plate	-	2	£97.60 (Exc VAT)	?	0
17	382300372	Gasket	-	2	£2.90 (Exc VAT)	?	0
18	382300802	Air Vent	-	2	£35.80 (Exc VAT)	?	0
19	382300371	Gasket	-	2	£11.90 (Exc VAT)	?	0
20	382300374	Gasket	-	1	£3.55 (Exc VAT)	?	0
21	666958..	RH LATERAL TRIM ASSEMBLY Optional- -Xeno headlights- -For order specify car number	-	1	POA		0
21	666966..	RH LATERAL TRIM ASSEMBLY Standard- -For order specify car number	-	1	POA		0
22	9811042..	LH LATERAL TRIM ASSEMBLY For order specify car number	-	1	POA		0
23	382300319	Bracket	-	2	£101.00 (Exc VAT)	?	0
24	66306900	Ring Nut	-	1	£84.60 (Exc VAT)	?	0
25	10977524	Screw	-	3	£1.35 (Exc VAT)	?	0
26	10519378	Washer	-	3	£1.35 (Exc VAT)	?	0
27	382310283	Complete Air Bag Framework	-	1	£53.30 (Exc VAT)	?	0
28	382300424	Pin	-	4	£1.10 (Exc VAT)	?	0
29	382300512	Plate	-	1	£6.40 (Exc VAT)	?	0
30	683407..	COMPLETE LOWER DASHBOARD COVER For order specify car number	-	1	POA		0
31	683330..	TUNNEL UPPER INSERT	-	1	POA		0
32	11620724	Screw.	-	2	£1.95 (Exc VAT)	?	0
33	9810011..	STEERING COLUMN BELLOWS For order specify car number	-	1	POA		0
34	9811043..	CENTRAL GASKET For order specify car number	-	1	POA		0
35	9811044..	LATERAL GASKET For order specify car number	-	1	POA		0
36	683401..	CENTRAL BODY IN THEDASHBOARD Texture lining- -For order specify car number	-	1	POA		0
36	687640..	CENTRAL BODY IN THEDASHBOARD Leather lining- -For order specify car number	-	1	POA		0
37	67526900	Fonoisolante Retroplancia	-	1	£124.00 (Exc VAT)	?	0
38	67524600	RH Insulation Panel	-	1	£35.70 (Exc VAT)	?	0
39	67524700	Fonoisolante Sottoplancia Sx	-	1	£40.10 (Exc VAT)	?	0
40	14059111	Nut	-	5	£1.00 (Exc VAT)	?	0
41	12638101	Washer	-	5	£1.10 (Exc VAT)	?	0
42	68333200	Bracket	-	1	£39.90 (Exc VAT)	?	0
43	13273914	Vite Tcic Pz M 5X 10	-	1	£1.35 (Exc VAT)	?	0
44	12637821	Split Washer	-	1	£1.10 (Exc VAT)	?	0
